Creating Game Environment Structures (2)

Character concept & blueprint creation

Indian MARCOS. Special ops gear.

Character modeling

Assignment Details:

1. Overview:

Starting with a concept, create a textured character model in Max as per the detailed specification and sample model provided. The model created needs to accurately represent the concept and real world references in terms of scale, proportions and shape.

2. Technical specification in brief:

The concept created needs to represent a sports character for a 3D game. The model created needs to accurately represent the concept character and real world reference in terms of scale, proportions and shape. The model created needs to follow the sample model in terms of mesh and texture detail and distribution. The triangle budget for the model is 3000 triangles and should use two textures, 512 x 512 and 10248 x 1024 24 or 32 bit textures for the head and body respectively.

Hard surface(car) modeling

Assignment Details:

1. Overview:

Create a textured car model in Max as per the detailed specification and sample model provided. The model created needs to be accurate in terms of scale, proportions and shape.

2. Technical specification in brief:

The model created needs to be accurate in terms of scale, proportions and shape. The model needs to match line drawings and primary reference images. The model created needs to follow the sample model in terms of mesh and texture detail and distribution. The triangle budget for the model is 4500 triangles excluding the 4 wheels. The entire model excluding wheels should use one 512 x  512 32 bit texture with the master psd created 1024 x 1024. The wheel model needs to follow the sample in terms of its construction and could use the wheel textures provided with the sample.

organic sculpting

Assignment Details:

1. Overview:

Create a High detail creature 3D sculpt in ZBrush, texture and generate Normal Maps from zbrush. The model created needs to represent the provided reference accurately.

The polycount for the low resolution Max model is 3000 tris.

2. Technical specification in brief:

The base model created needs to be accurate in terms of scale, proportions, shape and has to be well constructed for working in Zbrush. The high detail model needs to be created in ZBrush and the detailing and color texture should accurately represent the provided reference.

Inorganic sculpting

Assignment Details:

1. Overview:

Create a High detail 3D model in ZBrush for generation of Normal Maps. The model created needs to represent the provided reference accurately.

2. Technical specification in brief:

The base model created needs to be accurate in terms of scale, proportions, shape and has to be well constructed for working in Zbrush. The high detail model needs to be created in ZBrush and the detailing should accurately represent the provided reference.

1. Low Res Base Mesh. The base model needs to be accurate representation of the reference in terms of scale, proportions and shape. The base mesh needs to have proper divisions and should be constructed using quads in max. Triangles should be avoided as much as possible.
2. High Res Sculpt Model. Importing the base in proper format. All the visible details and features need to be sculpted.
3. Final submission. The final submission consists of the low res model with normal maps in Max and the high res ZBrush model.

Creating Game Environment Structures

Assignment Details:

Developing a Game environment concept and thereafter modeling and texturing the same for an FPS game.

The theme for this assignment is flee market shops from the game ‘Assassins Creed’

Based on the above theme, each student needs to creatively conceptualize a shop or similar environment model including any props associated that would fit this world. Further to which the student needs to create the model and texture it as per the detailed specification provided later in this document.

Additional to individual work, this task calls for team work to ensure that all models created look homogeneous.

However the submissions would be assessed based on individual models only.

1. Technical specification:

                Only the exterior of the environment model is to be created. This environment model is              targeted to fit in the ‘First person shooter’ game. Please note, the player can get close to this              model, however will not be able to enter.

·         This game engine expects environment models to fit in 10(L) x 10(B) x 10(H) ft blocks.

·         The environment model created can use one or two such blocks.

·         Here below is a reference of expected quality benchmark

·         The model can be viewed from all four sides, though the front is most important. Listing in order of priority for detail and pixel ratio it would be front, sides, back, roof. Please note the bottom surface will not be seen.

·         Triangle budget for the entire scene is 2000

·         Texture: 1 No x 2048 x 2048 pixels (24 or 32 bit)

·         Pixel ratio – 5 ft X 5 ft square on the ground floor should use 512 x 512 pixels

·         Texture format: ‘.Tga’ (corresponding ‘PSD’ with all the layers)

·         Final model needs to be one single object in MAX.

·         The model should use One multi sub object material
